Features:
1. With variable speed.
2. Driven by gear with high torque.
3. Large capacity for drilling and tapping
4. Casting iron structure for long durability
5. Coolant as standard
6. Safety guard with Microswitch
7. Variable speed
8. With a mechanical automatic feed
Specification:
|
Item No. |
190031 |
|
Model |
DP-40 |
|
Max. drilling capacity |
MT4 40mm |
|
Max. taping capacity |
25 mm |
|
Swing |
530 mm |
|
Spindle taper |
MT4 |
|
Spindle travel |
150 mm |
|
Spindle speed |
245-2000 rpm 65-540 rpm |
|
Spindle nose to table |
605 mm |
|
Spindle nose to base |
1150 mm |
|
Quill diameter |
75 mm |
|
Column diameter |
115 mm |
|
Motor power |
1.5 kW |
|
Table size |
22x18 IN |
|
Table slot |
16 mm |
|
Base size |
19x27 IN |
|
Machine size |
23x37x79 IN |
|
Net weight |
855 lbs |
|
Packing Size |
26"LX43"W x 88"H |
|
Gross Weight |
1120 lbs |
Accessories:
Standard Accessories for DP-40:
1. Handle crank Qty: 1PC
2. Arbor MT4-B16 Qty: 1PC
3. Drill Chuck (3-16mm)with key QTY: 1PC
IMPORTANT NOTICE
Shipping covers only Public Business Address with dock or forklift.
Optional shipping charge:
Following Value Added Service in the transportation is at extra charge. Please contact us before you place order. Thanks.
1. Residential delivery, includes power lift gate service, call before delivery service Extra charge $99
https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/extra-shipping-charge
2. Power tail gate service for public business address $50
https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/lift-gate-shipping-service
3. Call before delivery for business address $35
https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/appointment-service
