KAKA INDUSTRIAL  |  SKU: 188016V115

Kaka Industrial BS-76G, 7.8"x6.7" horizontal bandsaw, 115V-60HZ-1PH Metal Cutting Band Saw, Solid Design Metal Bandsaw, High Precision Metal Band Saw, Space Saver Metal Cutting Band Saw

C$2,499.99 CAD C$2,599.99
Shipping calculated at checkout.

Care information

Delivery and Shipping

  1. If the item weighs less than 145 lbs, it will be delivered by UPS, Purolator, FedEx Ground, Canpar, Canada Post and other couriers to the address you provided as the 'shipping address' when you placed the order. You will receive the tracking number once the carrier picks up.
  2. If the item weights over 145lbs normally will be delivered by LTL Freight. Please note you may need the optional services if you order these items. For example, if you don’t have a forklift or similar equipment to offload the package, you may need to book the lift gate delivery service when checkout.

SHIPPING OPTIONS:

KAKA INDUSTRIAL  uses UPS, Purolator ,Fedex Ground, Canpar, Canada post ,etc and  truck freight lines to ship your orders.

KAKA INDUSTRIAL  makes every effort to process orders within 24hrs of being placed. You will receive a shipping confirmation email that will confirm which carrier is used for your products.

If your order is less than 145lbs, it could be delivered byUPS, Purolator ,Fedex Ground, Canpar, Canada post and other courier to the address you provided as 'shipping address' when you placed the order. If your order is above 145lbs, it will be delivered by Freight company that has been picked to minimize the cost of delivery to your area.  In this case, your delivery address must be accessible by tractor-trailer , and In some cases your shipping fee may be different than displayed online.

Truck drivers are not required to assist with unloading. You are responsible for unloading your freight and for moving it into your shop. For residential delivery and shops without a loading dock, liftgate delivery is available for an additional charge.

You can also arrange to pick up your freight at the carrier's terminal. The carrier will load the item onto your vehicle. If you choose this option, please make sure your vehicle is capable of handling the weight and bring plenty of tie-downs to secure the load properly .

Extra Shipping Service Charges:

1. Residential delivery, includes power lift gate service, call before delivery service Extra charge $120

https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/extra-shipping-charge

2. Power tailgate service for  business address $50

https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/lift-gate-shipping-service

3. Call before delivery for business address

https://www.kakaindustrial.ca/collections/extra-shipping-charge/products/appointment-service



REDELIVERY OF FREIGHT

When, through no fault of carrier and after reasonable effort, redelivery is requested, a charge of $99.00 will be assessed against the shipment in addition to accrued charges.

DELIVERY TIMES:

Delivery times are expected, not guaranteed. If payment authorization is delayed, in order to confirm payment or prevent fraud, Kaka Industrial reserves the right to delay shipments. Every effort will be made to ship at the soonest possible time.

THINGS TO KNOW:

  • Weather delays and other circumstances may impact delivery time. Estimated arrival dates are not guaranteed.
  • Deliveries to New Brunswick, Prince Edward Island, Nova Scotia and Newfoundland/Labrador will take longer.
  • All shipping timeframes and/or shipping methods/providers listed on www.kakaindustrial.ca are to be considered estimates and are not guaranteed.



 ***We automatically email your tracking number when your order ships***

Payment & Security

Payment methods

  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

1. Rigid cast-iron design with steel base serving as the utility shelf
2. Coolant pump ensures the longer service life of saw blade and improve the precision of workpiece
3. Scale on the vise allows easy adjustments for angle cuts
4. Quick adjusting vise for angular cuts—the saw frame swivels, not the material.
5. Hydraulic cylinder for controlled descent
6. Accident preventing devices on the fly wheel casing and on the blade
7. Vertical rotation on bolt with adjustable tapered bearings without backlash
8. Band stretching is obtained by electro-mechanical blade tension with micro switch
9. European design, dovetail-type clamp movement and locking mechanism
10. Worm gear box transmission structure
11. The calibration of the jaw is convenient for adjustment and positioning at any angle (Scale on
the vise allows easy adjustments for angle cuts)
12. The falling speed of saw bow is controlled by hydraulic cylinder
13. The European design band saw has a sizing device (machine will stop automatically after sawing
materials)
14. The European design band saw has power break protection device (machine will power off
automatically when the rear protective cover is opened)
15. It is equipped with a block feeder (with fixed sawing length)
16. The European design band saw has a sizing device (machine will stop automatically after sawing
materials)
17. The European design band saw has power break protection device (machine will power off
automatically when the rear protective cover is opened)
18. It is equipped with a block feeder (with fixed sawing length)
Item No.
188016V115
Model
BS-76G
Capacity
Circular @90°
170 mm (6.7”)
Rectangular @90°
200x170 mm (7.8”x6.7”)
Circular @60°(right)
70 mm (2.7”)
Rectangular @60°(right)
60x60 mm (2.3”x2.3”)
Circular @45° (right)
120 mm (4.7”)
Rectangular @45°(right)
110x110 mm (4.3”x4.3”)
Blade speed @ 50Hz
2P,80 MPM 262 FPM
Blade speed @ 60Hz
4P,40 MPM 131 FPM
Blade size
20X0.9X2085 mm
Motor power
1.5 HP / 1100w,  115V Single phase
Drive
Gear
Packing size (body)
49x28x40 in
Packing size (stand)
Together with in body
N.W./G.W.
381 / 496 lb

1.KAKA Industrial provides 12 months warranty for this product from the date of purchase.

2. Please note that this warranty does not apply to defects due directly or indirectly to misuse, abuse, alterations, lack of maintenance or consumable parts.

3. The original end-user must give written notice to Seller of any suspected defect in the Goods prior to the expiration of the warranty period.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
KAKA INDUSTRIAL

Kaka Industrial BS-76G, 7.8"x6.7" horizontal bandsaw, 115V-60HZ-1PH Metal Cutting Band Saw, Solid Design Metal Bandsaw, High Precision Metal Band Saw, Space Saver Metal Cutting Band Saw

C$2,499.99 CAD C$2,599.99
Description
1. Rigid cast-iron design with steel base serving as the utility shelf
2. Coolant pump ensures the longer service life of saw blade and improve the precision of workpiece
3. Scale on the vise allows easy adjustments for angle cuts
4. Quick adjusting vise for angular cuts—the saw frame swivels, not the material.
5. Hydraulic cylinder for controlled descent
6. Accident preventing devices on the fly wheel casing and on the blade
7. Vertical rotation on bolt with adjustable tapered bearings without backlash
8. Band stretching is obtained by electro-mechanical blade tension with micro switch
9. European design, dovetail-type clamp movement and locking mechanism
10. Worm gear box transmission structure
11. The calibration of the jaw is convenient for adjustment and positioning at any angle (Scale on
the vise allows easy adjustments for angle cuts)
12. The falling speed of saw bow is controlled by hydraulic cylinder
13. The European design band saw has a sizing device (machine will stop automatically after sawing
materials)
14. The European design band saw has power break protection device (machine will power off
automatically when the rear protective cover is opened)
15. It is equipped with a block feeder (with fixed sawing length)
16. The European design band saw has a sizing device (machine will stop automatically after sawing
materials)
17. The European design band saw has power break protection device (machine will power off
automatically when the rear protective cover is opened)
18. It is equipped with a block feeder (with fixed sawing length)
Item No.
188016V115
Model
BS-76G
Capacity
Circular @90°
170 mm (6.7”)
Rectangular @90°
200x170 mm (7.8”x6.7”)
Circular @60°(right)
70 mm (2.7”)
Rectangular @60°(right)
60x60 mm (2.3”x2.3”)
Circular @45° (right)
120 mm (4.7”)
Rectangular @45°(right)
110x110 mm (4.3”x4.3”)
Blade speed @ 50Hz
2P,80 MPM 262 FPM
Blade speed @ 60Hz
4P,40 MPM 131 FPM
Blade size
20X0.9X2085 mm
Motor power
1.5 HP / 1100w,  115V Single phase
Drive
Gear
Packing size (body)
49x28x40 in
Packing size (stand)
Together with in body
N.W./G.W.
381 / 496 lb
Manual

BS-76G Manual
